API 5L Gr. B PSL1 10” SCH STD ERW Steel Pipe
Product Overview
API 5L Gr. B PSL1 10" SCH STD ERW Steel Pipe is a high-frequency electric resistance welded line pipe manufactured in strict accordance with API 5L PSL1 standard. Made of high-quality carbon steel with advanced ERW technology, it features stable mechanical properties, precise dimensions and cost-effectiveness, making it the mainstream choice for medium and low-pressure applications such as oil & gas transmission, municipal engineering and industrial fluid transportation worldwide.
Core Specifications
Standard: API 5L PSL1 (equivalent to L245 line pipe steel)
Material: API 5L Grade B Carbon Steel (C≤0.28%, Mn≤1.20%, P≤0.030%, S≤0.030%)
Dimension: 10 inches, SCH STD standard wall thickness (9.27mm)
Mechanical Properties: Yield Strength ≥245MPa, Tensile Strength ≥415MPa, Elongation ≥23%
Process: High-Frequency Electric Resistance Welding (ERW), 100% online UT & hydrostatic testing for welds
Length: Standard 6m/12m, customizable available
Key Advantages
Global Standard ComplianceFully compliant with API 5L PSL1 international line pipe standard, compatible with mainstream specifications like ASTM A53 Grade B. Meets global engineering procurement and construction requirements. Provides authoritative inspection documents including EN 10204 3.1, satisfying strict access conditions for oil & gas and municipal projects.
Reliable ERW TechnologyAdopts high-frequency resistance welding, ensuring uniform microstructure between weld and base metal with mechanical properties close to parent material. Online heat treatment eliminates welding stress, delivering uniform wall thickness, smooth inner/outer surfaces, excellent air-tightness and structural stability to prevent leakage risks.
Precise Dimensions for Efficient InstallationStrictly controlled dimensional tolerances, with OD, wall thickness and straightness accuracy exceeding industry standards. Facilitates on-site welding and connection, reduces installation deviations, shortens construction period and lowers overall engineering costs.
Balanced Performance for Wide AdaptabilityFeatures excellent toughness, weldability and corrosion resistance, suitable for medium and low-pressure fluid transmission. With anti-corrosion coatings, it ensures long-term stable operation in complex environments like marine and chemical industries, with service life exceeding 50 years.
Cost-Effective & Stable Mass ProductionHigh automation and production efficiency of ERW process balance quality and cost, ideal for large-scale pipeline project procurement. Adequate stock and short customization lead time meet fast project delivery requirements.
Application Areas
Municipal Engineering: Urban water supply/drainage mains, sewage treatment, heat transmission pipelines.
Industrial Fluids: Chemical medium transmission, power plant circulating water, industrial cooling system pipelines.
Structural Engineering: Bridge supports, port & dock pile pipes, steel structure columns, heavy equipment foundations.
Service & Guarantee
Provides complete material certificates, inspection reports, EN 10204 3.1 certification and other documents.
Supports customized length, bevel processing, anti-corrosion coating (3PE/3PP/FBE) and other deep processing services.
Professional technical team provides selection and installation guidance throughout pre-sales, sales and after-sales.
Global logistics distribution, container shipping available, adaptable to multiple port deliveries.
